计算机生成的全息图 (CGH)

计算机生成的全息图,是一种神奇的波前“转换器”,可以将干涉仪的标准测试波前,转化成为非球面测试波前,从而让普通激光干涉仪,能用于各类非球面面形测量

Computer Generated Hologram

金刚石车削和小工具确定性抛光的进展,极大地提高了光学制造能力,几乎可以生产任何表面形状。设计师们利用这些能力,越来越多地将非球面光学器件设计到成像、传感和激光系统中,以提高性能,减少光学系统的尺寸和重量。

然而,生产高质量的非球面光学器件所需要的不仅仅是抛光设备,还需要计量学来指导抛光和表面材料的去除,使之趋向于与设计紧密匹配的理想表面图形。

CGH(计算机生成全息图)计算机生成的全息图,是一种神奇的波前“转换器”,可以将干涉仪的标准测试波前,转化成为非球面测试波前,从而让普通激光干涉仪,能用于各类非球面面形测量。

Zygo的Verifire VTSVerifire™非球面产品非常适合CGH应用的生产级非球面和自由形态光学。
  • 更多信息
  • 宣传册和
    规格表
  • 应用
    指南
  • 应用
    指南
  • 使用手册
  • 技术论文
  • 视频

Verifire™ MST 可对光学元件和镜头系统的表面形貌和透射波前进行高精度测量。它是唯一一个可以同时测量多个表面形貌的商用干涉仪系统,可以保持相对表面信息,并快速提供多个表面的结果。

主要特点

  • 同时进行表面和波前表征,还可进行精确的面与面之间的测量,如 TTV 和楔角
  • 薄至 0.5 mm 的测试样件的表面形貌和厚度分析
  • 广泛的横向分辨率,包括像素限制的光学设计,可提供最佳的 ITF
    • 1.2k x 1.2k(包括分立变焦,可实现高达 3 倍的光学变焦(适用于进口干涉仪))
    • 2.3k x 2.3k
    • 3.4k x 3.4k
  • 工作波长为 633 nm 到 1.053 µm、1.064 µm 和 1.55 µm
  • ZYGO 独有的 QPSI™ 采集技术,可在振动较常见的环境中实现可靠的测量,该技术现在可用于波长移相和多表面 FTPSI 数据采集
  • Ring of Fire火环伪影减少源为标准配置,可消除靶心并降低相干噪声



Laser Interferometers
Laser Interferometers
Verifire™ MST Plus
Verifire™ MST+
Verifire™ HD-MST
Verifire™ HDX-MST
Verifire™ MST IR
Laser Interferometer Accessory Guide
Interactive Transmission Sphere Selector
Interferogram Interpretation and Evaluation Guide
Horizontal Radius Metrology Specs
Transmission Sphere Selection Guide
Typical Interferometer Setups Guide
Transmission Spheres Specs
标题
文件
下载链接
Laser Interferometers
DocumentBrochure
下载链接 下载
Laser Interferometers
DocumentBrochure
下载链接 下载
Verifire™ MST Plus
DocumentSpecifications
下载链接 下载
Verifire™ MST+
DocumentSpecifications
下载链接 下载
Verifire™ HD-MST
DocumentSpecifications
下载链接 下载
Verifire™ HDX-MST
DocumentSpecifications
下载链接 下载
Verifire™ MST IR
DocumentSpecifications
下载链接 下载
Laser Interferometer Accessory Guide
DocumentBrochure
下载链接 下载
Interactive Transmission Sphere Selector
DocumentInteractive Document
下载链接 下载
Interferogram Interpretation and Evaluation Guide
DocumentReference Guide
下载链接 下载
Horizontal Radius Metrology Specs
DocumentSpecifications
下载链接 下载
Transmission Sphere Selection Guide
DocumentBrochure
下载链接 下载
Typical Interferometer Setups Guide
DocumentBrochure
下载链接 下载
Transmission Spheres Specs
DocumentSpecifications
下载链接 下载
Measurement of Aspheric Surfaces
Determining Asphere Measurability
Grazing Incidence Testing
Interferogram Scale Factor
Silver Overcoat Spray
Testing Cylindrical Surfaces with Computer Generated Holograms
Fringe Analysis versus Phase Measuring Interferometry
Finite Conjugate Lens Testing
标题
文件
下载链接
Measurement of Aspheric Surfaces
DocumentAN-0007
下载链接 下载
Determining Asphere Measurability
DocumentAN-0008
下载链接 下载
Grazing Incidence Testing
DocumentAN-0010
下载链接 下载
Interferogram Scale Factor
DocumentAN-0015
下载链接 下载
Silver Overcoat Spray
DocumentAN-0016
下载链接 下载
Testing Cylindrical Surfaces with Computer Generated Holograms
DocumentAN-0017
下载链接 下载
Fringe Analysis versus Phase Measuring Interferometry
DocumentAN-0018
下载链接 下载
Finite Conjugate Lens Testing
DocumentAN-0019
下载链接 下载
Testing Cylindrical Optics
DocumentAN-0020
下载链接 下载
MetroPro® Cylinder Tools
DocumentAN-0021
下载链接 下载
Verifire™ MST 633 nm
Verifire™ 633 nm MST Plus, HD MST, HDX MST
Verifire™ MST 1550 nm
干涉图解读和评估
激光干涉仪配件指南
激光干涉仪配件指南
激光干涉仪配件指南
激光干涉仪配件指南
激光干涉仪快速设置指南
透射球面镜选择指南
透射球面镜选择器(交互式 Excel® 文档)
Mx™ 快速入门指南
Mx™ 参考指南
Mx™ 远程访问指南
标题
文件
下载链接
Verifire™ MST 633 nm
DocumentOMP-0515E
下载链接 下载
Verifire™ 633 nm MST Plus, HD MST, HDX MST
DocumentOMP-0628A
下载链接 下载
Verifire™ MST 1550 nm
DocumentOMP-0481A
下载链接 下载
干涉图解读和评估
DocumentInterEval.pdf
下载链接 下载
激光干涉仪配件指南
DocumentOMP-0463AM
下载链接 下载
激光干涉仪配件指南
DocumentOMP-0634A
下载链接 下载
激光干涉仪配件指南
DocumentOMP-0635A
下载链接 下载
激光干涉仪配件指南
DocumentOMP-0598A
下载链接 下载
激光干涉仪快速设置指南
DocumentOMP-0584A
下载链接 下载
透射球面镜选择指南
DocumentTS_Selection.pdf
下载链接 下载
透射球面镜选择器(交互式 Excel® 文档)
DocumentOMP-0495E
下载链接 下载
Mx™ 快速入门指南
DocumentOMP-0570D
下载链接 下载
Mx™ 参考指南
DocumentOMP-0550D
下载链接 下载
Mx™ 远程访问指南
DocumentOMP-0600A
下载链接 下载
Solutions for environmentally robust interferometric optical testing
101 Frame Algorithm For Phase Shifting Interferometry
A next-generation optical surface form inspection instrument for high-volume production applications
A review of selected topics in interferometric optical metrology
Absolute distance measurements using FTPSI with a widely tunable IR laser
Absolute Interferometric Testing of Spherical Surfaces
Absolute Measurement of Rotationally Symmetrical Aspheric Surfaces
Adjustable coherence depth in a geometrically-desensitized interferometer
标题
文件
下载链接
Solutions for environmentally robust interferometric optical testing
Document技术论文
下载链接 下载
101 Frame Algorithm For Phase Shifting Interferometry
Document技术论文
下载链接 下载
A next-generation optical surface form inspection instrument for high-volume production applications
Document技术论文
下载链接 下载
A review of selected topics in interferometric optical metrology
Document技术论文
下载链接 下载
Absolute distance measurements using FTPSI with a widely tunable IR laser
Document技术论文
下载链接 下载
Absolute Interferometric Testing of Spherical Surfaces
Document技术论文
下载链接 下载
Absolute Measurement of Rotationally Symmetrical Aspheric Surfaces
Document技术论文
下载链接 下载
Adjustable coherence depth in a geometrically-desensitized interferometer
Document技术论文
下载链接 下载
Advances in optical metrology
Document技术论文
下载链接 下载
Applications of optical coherence in interferometric metrology
Document技术论文
下载链接 下载
